Shenzhen, China – October 2026
ElisaCustom is pleased to announce the release of our new 25mm Pixel Bubble Tube Light (Model: XXA-TUBE-D25L200) — a compact and vibrant lighting solution designed for dynamic color effects in a variety of applications. Featuring 3 SMD3535 RGB LEDs, 360° beam angle, DC12V operation, and WS2811/UCS1903 IC options, this 25mm diameter tube delivers brilliant full-color illumination with individual pixel control.
Ideal for architectural accents, signage, event decorations, and retail displays, the XXA-TUBE-D25L200 offers both visual impact and reliable performance.
What Makes This Pixel Bubble Tube Unique?
Feature | Specification |
|---|---|
Product Name | Pixel Bubble Tube Light |
Model | XXA-TUBE-D25L200 |
Diameter | 25mm |
Length Options | 200mm / 150mm / 50mm |
LED Type | 3 × SMD3535 RGB LEDs |
IC Options | WS2811 / UCS1903 |
Voltage | DC12V |
Power | 0.72W per unit |
Beam Angle | 360° |
Mounting Hole | 19mm |
Connector | 3-pin male/female connectors |
Working Temperature | -20°C to +60°C |
Key Features
1. 3 SMD3535 RGB LEDs – Vibrant Full-Color Output
The tube features 3 high-brightness SMD3535 RGB LEDs, delivering:
Rich, saturated colors for dynamic effects
Individual pixel control — each LED can be addressed separately
Smooth color mixing — 256 grayscale levels per channel (WS2811)
2. 360° Beam Angle – Wide, Uniform Illumination
The 360° beam angle ensures:
Even light distribution from every angle
No dark spots or shadows
Versatile placement — suitable for surface or pendant mounting
3. Compact 25mm Diameter – Versatile Size
The 25mm diameter is ideal for:
Tight installation spaces
Architectural accents — clean, discreet appearance
Signage and channel letters — where smaller light points are required
4. WS2811 / UCS1903 IC Options – Pixel-Level Control
IC Option | Protocol | Best For |
|---|---|---|
WS2811 | SPI | Cost-effective, widely compatible |
UCS1903 | SPI | Reliable performance, 256 grayscale |
Both ICs provide:
Individual addressability — each LED controlled independently
256 grayscale levels — smooth, professional color transitions
Single-wire data transmission — easy cascading
5. 3-Pin Connectors – Easy Daisy-Chaining
The 3-pin male/female connectors provide:
Simple daisy-chaining — extended runs with minimal wiring
Secure connections — reliable signal and power transmission
6. Multiple Length Options – Flexible Installation
Length | Best For |
|---|---|
200mm | Standard accent lighting |
150mm | Compact installations |
50mm | Short accents, tight spaces |
7. 19mm Mounting Hole – Easy Installation
The 19mm mounting hole is a standard size, making it:
Easy to integrate into existing installations
Compatible with most signage and architectural fixtures
Quick to install with minimal preparation
8. Low Power Consumption – 0.72W per Unit
With only 0.72W per unit, this tube is:
Energy-efficient — reduces operating costs
Suitable for long runs — lower total power demand
Environmentally friendly — minimal energy waste
Technical Specifications
Parameter | Value |
|---|---|
Product Name | Pixel Bubble Tube Light |
Model | XXA-TUBE-D25L200 |
Diameter | 25mm |
Length Options | 200mm / 150mm / 50mm |
LED Type | 3 × SMD3535 RGB |
IC Options | WS2811 / UCS1903 |
Voltage | DC12V |
Power | 0.72W per unit |
Beam Angle | 360° |
Mounting Hole | 19mm |
Connector | 3-pin male/female |
Working Temperature | -20°C to +60°C |
Applications
Application | Why This Tube Fits |
|---|---|
Architectural accents | 360° beam, compact 25mm diameter |
Signage & channel letters | Pixel control, vibrant colors |
Event & party decorations | Dynamic effects, easy installation |
Retail displays | Eye-catching, low power consumption |
Bar & restaurant lighting | Atmosphere creation, color-changing effects |
Installation Overview
Step | Action |
|---|---|
1 | Mark and drill a 19mm mounting hole |
2 | Insert the tube into the hole |
3 | Connect the 3-pin male/female connectors for power and signal |
4 | Connect to a compatible SPI controller and DC12V power supply |
5 | Power on and test |
Summary
Advantage | Benefit |
|---|---|
3 SMD3535 RGB LEDs | Vibrant full-color output |
360° beam angle | Even, wide illumination |
WS2811 / UCS1903 options | Pixel-level control, 256 grayscale |
DC12V operation | Safe, efficient, standard voltage |
25mm diameter | Compact, versatile size |
Multiple lengths | 200mm / 150mm / 50mm options |
3-pin connectors | Easy daisy-chaining |
0.72W per unit | Low power consumption |
Related Reading
New 75mm RGBW Pixel Light – SPI (TM1824) & DMX Models, DC24V →
New D40mm 360° RGB Pixel Tube – SPI/DMX, 144 LEDs, DC12V/24V →
New 3D Neon Infinity Mirror – Endless Depth, Endless Possibilities →
Availability
The new 25mm Pixel Bubble Tube Light (XXA-TUBE-D25L200) is available for order now. Custom lengths and configurations are available upon request.
